Custom Conveyor Toasters Motor
Reliable, Low-Noise, High-Temperature Motors for Conveyor Toasters & Food Equipment
Fengtech supplies shaded-pole motors for conveyor toasters; these motors feature a long service life and high torque, driving the conveyor belt to ensure that bread is heated evenly during transport. With customizable speeds, these motors are ideally suited for commercial environments, significantly enhancing the efficiency of the toasting process.
Applications of Conveyor Toaster Motors
• Commercial Conveyor Toasters
• Bread Toasting Lines
• Fast Food Kitchen Equipment
• Hotel Breakfast Machines
• Bakery Heating Equipment
How the Motor Works in a Conveyor Toaster
Drives the conveyor belt (controlling the speed at which the bread moves).
Determines the toasting time.
Ensures stable, low-speed operation over extended periods.
Our Toaster Motor Customization Options
Speed (RPM)
Torque
Shaft size / shape
Voltage / frequency
Mounting structure
Gear ratio
Other
Toaster Motors Manufacturing Cases
YJF-6440 (AC220V 5RPM)
| 1. Rated Characteristics | |||
|---|---|---|---|
| No. | Item | Specification | Remark |
| 1.1 | Rated Voltage | AC230V / 50Hz | |
| 1.2 | No load Power | ≤45W | |
| 1.3 | No load Current | ≤0.3A | |
| 1.4 | No load Speed | 5.0RPM | |
| 1.5 | Stall Touqer | ≥200 kgf.cm | |
| 1.6 | Rotation | CW | |
| 1.7 | Dielectric Str. | AC1800V for 1s | |
| 1.8 | Insulation Class. | Class B | |
| 1.9 | Insulation Res. | ≥100M ohm | |
| 2.1 | Environment | -10℃ ~ +50℃ | |
| 2.2 | Noise | ≤55dbtd> | |
