▍ODM/OEM
Reliable BLDC Manufacturer&Supplier with 20 Years of Customization Experience
▍내장형 드라이브 DC 브러시리스 모터
▍고효율, 긴 수명, 저진동, 저소음
▍속도 조향 제어 피드백, 무단 속도 조절
▍임피던스 보호/온도 보호
▍사용자 지정 지원
Design & Applications of Brushless DC Motors
Fengtech’s designed and manufactured brushless DC motors have been applied in various fields, including cross-flow fans and ice maker water pumps. Their long lifespan, low noise, and strong stability make them the preferred motor for many manufacturing plants. We also provide fully customized production and services to meet diverse application scenarios and requirements. If your project requires brushless DC motors and you are unsure about the design and debugging process, please contact our engineering team. Below are some examples of brushless DC motor design and production cases in various industries:
제품 카테고리
문의하기
닝보 펑테크 모터 주식회사
Address: ShangshuiQi, Dongqiao, Haishu, Ningbo, China
TEL：0086-574 8826 9878
Moblie：86-15314581799
E-mail: export@fengtech.com
Related Articles
-
브러시리스 DC 모터FN-BL70
입력 전압: 12/24VDC
입력 전원: 10~80W
속도 범위: 0~3500RPM
출력 전력: 6~50W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 1.0~5.0A -
브러시리스 DC 모터
BL7020
입력 전압: 12/24VDC
입력 전원: 10~80W
속도 범위: 0~3500RPM
출력 전력: 6~50W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 1.0~5.0A -
브러시리스 DC 모터
BL6010
입력 전압: 12/24VDC
입력 전원: 5~20W
속도 범위: 0~2800RPM
출력 전력: 3~10W
타코미터: 9PPR
방향 회전: 양방향
컷텐트 제한: 1~2.0A -
브러시리스 DC 모터
FAS-BL70
입력 전압: 12/24VDC
입력 전원: 30~60W
속도 범위: 0~2800 RPM
출력 전력: 20~45W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 2.0~5.0A -
브러시리스 DC 모터
GM-BL60
입력 전압: 12/24VDC
입력 전원: 5~20W
속도 범위: 0~2800RPM
출력 전력: 3~10W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 1~2A -
브러시리스 DC 모터
TT-BL60
입력 전압: 12/24VDC
입력 전원: 5~20w
속도 범위: 0~2800RPM
출력 전력: 3~10W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 1.0~2.0A -
브러시리스 DC 모터
FA-BL60
모델:FA-BL60
입력 전압: 12 또는 24VDC
입력 전력: 10~30W
속도 범위: 0~2800RPM
출력 전력: 9PPR
회전 방향: 양방향
전류 제한: 1.0~3.0A -
브러시리스 DC 모터
FAS-BL60
입력 전압: 12 또는 24VDC
입력 전력: 20~30W
속도 범위: 0~2800RPM
출력 전력: 10~20W
타코미터: 9PPR
방향 회전: 양방향
전류 제한: 1.5~3.0A
Downloads
Download detailed technical documents for our custom BLDC motors. All files are provided by our in-house engineering team.
Brushless Dc Motor Production Site
Fengtech independently handles the entire process from motor design and raw material procurement to production, manufacturing, and assembly. The factory is equipped with modern motor installation and testing equipment, and every step of the process is recorded in a management system for continuous monitoring.
Our BL6010 and BL7020 series brushless motors have wide applications in refrigeration, food machinery, pumps, and other fields. They offer customizable speeds from 0-3500 RPM, a maximum voltage of 80W, and bidirectional rotation. They are also CE and CCC certified, meeting the requirements of most applications.
Automated Production and Quality Control
Automatic Motor Bracket Installation
Automatic Circuit Welding
Motor Testing System
Automatic Motor Bracket Installation
Motor Mounting Equipment
Motor Housing Die Casting
BLDC Motor - Customization Range
| Customization Item | Available Options |
|---|---|
| Rated Voltage | 12V / 24V / 36V / 48V / Customized |
| Speed (RPM) | 0 – 4,000 RPM (customized) |
| 토크 | Customized according to load requirement |
| Output Power | 0W – 300W (optional) |
| Shaft Type | Round shaft / D-shaft / Keyed shaft / Customized |
| Mounting Type | Flange mount / Foot mount / Customized |
| Control Type | Sensor / Sensorless |
| Protection Level | IP20 / IP44 / IP54 / IP65 (on request) |
| 소음 수준 | Low noise design available (≤50 dB) |
| Connector & Wiring | Lead wire length / Terminal / Connector (customized) |
| Certification | CCC / CE / RoHS /UL(available upon request) |
Learn more about bldc motor production cases:
|
이미지
|
모델
|
그리기
|
전압
|
출력 속도
|
회전
|
설치
|
|
BL6010 |
DC24V, 50Hz |
1500RPM |
CW/CCW |
|
|---|---|---|---|---|---|---|
|
|
BL7020 |
DC18~26V |
2300RPM |
CW/CCW |
|
|
|
|
BL7020(Extended Axis Version) |
DC18~26V |
2800RPM |
CW |
Water Pump |
자주 묻는 질문
The moq is 1000 units, and the delivery time is 30-45 days.
Absolutely, we can provide full customization from design, production, to packaging.
We have CCC, CE, UL, ROHS, and other certifications. Please contact us to obtain the certification certificates.
Typically 12V or 24V, but other parameters can also be customized.
Any shaft and mounting method is possible. You can provide relevant design drawings, and we will offer some suggestions.
The motor has a built-in temperature protection device. It will stop running when overheated to protect the motor.
We have over 20 years of experience in custom design. You can provide your requirements to our engineers, and they will provide reasonable suggestions.
We are located in Ningbo, Zhejiang, China. If you would like to visit, please contact us in advance to schedule an appointment. We look forward to welcoming you.
